| Bonded Phase | USP Listing | Particle Size (µm) | Pore Size (Å) | pH Range | Temp. Max °C (low pH) |
Temp. Max °C (high pH) |
Carbon Load (%) | Surface Area (m2/g) | Endcapped | Phase Structure | Applications | Buy |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AQ | L1 | 2* |
100 |
2-8 | 60 | 40 | 14.0 |
300 |
Yes | View | View | Buy Now |
| C18 | L1 | 2* |
100 |
2–8 | 60 | 40 | 15.5 |
300 |
Yes | View | View | Buy Now |
| C18-Amide | L1 | 2* |
100 |
2–8 | 60 | 40 | 16.4 |
300 |
Yes | View | View | Call for pricing |
| C18-AR | L1 | 2* |
100 |
2–8 | 60 | 40 | 15.5 |
300 |
Yes | View | View | Buy Now |
| C18-PFP | L1 | 2* |
100 |
2–8 | 60 | 40 | 14.3 |
300 |
Yes | View | View | Buy Now |
| C4 | L26 | 2* |
100 |
2-8 | 60 | 40 | 5.5 |
300 |
Yes | View | View | Buy Now |
| C8 | L7 | 2* |
100 |
2-8 | 60 | 40 | 9.0 |
300 |
Yes | View | View | Call for pricing |
| CN | L10 | 2* |
100 |
2-7 | 60 | 40 | 5.5 |
300 |
Yes | View | View | Call for pricing |
| CN-ES | L1 | 2* |
100 |
2–8 | 60 | 40 | 12.6 |
300 |
Yes | View | View | Call for pricing |
| NH2 | L8 | 3 |
100 |
2-7 | 60 | 40 | 3.5 |
300 |
No | View | View | Call for pricing |
| Phenyl | L11 | 2* |
100 |
2-8 | 60 | 40 | 9.5 |
300 |
Yes | View | View | Buy Now |
| SIL | L3 | 2* |
100 |
2-7 | 40 | 40 | N/A |
300 |
N/A | View | View | Buy Now |
| SuperC18 | L1 | 2* |
90 |
1.5-11.5 | 60 | 40 | 14.8 |
400 |
Encapsulated | View | View | Buy Now |
Additional Details
- Columns are pressure rated to 400 bar
- Avantor® ACE® microbore columns are available in 1.0 and 0.5 mm Column IDs available in 1/16” and 1/32” end-fittings in 2.0*, 3.0 and 5.0 µm particles sizes – Note: 2.0 µm particles sizes are only available in 1.0 mm and 0.5 mm IDs
- Avantor® ACE® capillary HPLC columns are available in 0.3 and 0.1 mm Column IDs
- Avantor® ACE® nano HPLC columns are available in 0.075 mm Column IDs
